Widney’s expertise in this area has helped shape the development of the ATM machine for both hole in the wall and in-lobby, stand alone machines.
The full slide range has been utilised with heavy duty slides used for safes and dispenser units and light duty slides used for monitors, printer units and micro card readers.
Refurbishment and cash replenishment would not be accomplished as efficiently in today’s equipment without the use of telescopic slides.
Take advantage of Widney's expertise and proven track record in this specialised market.
110 - Non Lock
Width 17.5-19.0mm
Height 34.0mm50kg (per pair)
120 - Removable Beam
Width 17.5-19.0mm
Height 34.0mm50kg (per pair)
130 - Latch In/Latch Out
Width 17.5-19.0
Height 34.0mm50kg (per pair)
140 - Non Lock
Width 10.5mm
Height 34.0mm50kg (per pair)
142 - Lock Out Removable Beam
Width 10.5mm
Height 34.0mm50kg (per pair)
210 - Non Lock
Width 18.5-20.0mm
Height 51.0mm90kg (per pair)
220/230 - Lock In/Lock Out
Width 18.5-20.0mm
Height 51.0mm90kg (per pair)
240 - Non Lock
Width 9.5-10.5
Height 51.0mm90kg (per pair)
250/260 - Lock Out
Width 18.5-20.0mm
Height 51.0mm90kg (per pair)
320 - Non Locking
Width 19.0mm
Height 56.0mm60kg (per pair)
5012 CN - Removable Beam
Width 11.8-12.7mm
Height 33.0mm70kg (per pair)
5012 FN - Non Locking
Width 11.8-12.7mm
Height 33.0mm70kg (per pair)
5012 TN - Lock Out Removable Beam
Width 11.8-12.7mm
Height 33.0mm70kg (per pair)
5030 - Non Lock
Width 19.5-20.5mm
Height 49.8mm190kg (per pair)
5035 - 100% Extension
Width19.8mm
Height 49.5mm130kg (per pair)
5040 - 100% Extension
Width 25.0-26.0mm
Height 68.0mm260kg (per pair)
5040 - 140% Extension
Width 25.0-26.0mm
Height 68.0mm170kg (per pair)
5045 -100% Extension
Width 25.0-26.0mm
Height 68.0mm135kg (per pair)
5045 -140% Extension
Width 26.0-25.0mm
Height 68.0mm92kg (per pair)
