CATERING
From basic drawer units to complex refrigerated storage cabinets, the Widney range of slides is used in commercial kitchens and food safe applications all over the world.Manufactured from high grade aluminium alloys, steel and stainless steel telesides offer a proven solution for catering equipment.
In the demanding food safe environment Widney’s slide range, incorporating various food safe and protective surface finishes, can be used in a wide variety of equipment including high and low temperature products. Using slides for access makes service, maintenance and cleaning of equipment simple and effective.
Widney’s engineers are available to help specify the right slide for the job.
110 - Non Lock
Width 17.5-19.0mm
Height 34.0mm50kg (per pair)
120 - Removable Beam
Width 17.5-19.0mm
Height 34.0mm50kg (per pair)
130 - Latch In/Latch Out
Width 17.5-19.0
Height 34.0mm50kg (per pair)
140 - Non Lock
Width 10.5mm
Height 34.0mm50kg (per pair)
142 - Lock Out Removable Beam
Width 10.5mm
Height 34.0mm50kg (per pair)
210 - Non Lock
Width 18.5-20.0mm
Height 51.0mm90kg (per pair)
220/230 - Lock In/Lock Out
Width 18.5-20.0mm
Height 51.0mm90kg (per pair)
240 - Non Lock
Width 9.5-10.5
Height 51.0mm90kg (per pair)
MEDICAL
Whether it’s National Heath Service, private hospitals, medical centres or ambulances, Widney’s light and heavy duty slides are widely used in medical equipment.-
Special purpose trolleys
-
Hospital beds
-
Xray equipment
-
Operating theatres
-
Morgue equipment
-
Wheelchair ramps
Yet again the materials used and surface finishes applied to Widney slides ensure that one of the products in the range will be suitable for your application.
Technical sales can offer one of our standard slides or specify a solution to meet your individual needs.
250/260 - Lock Out
Width 18.5-20.0mm
Height 51.0mm90kg (per pair)
410
Width 24.0mm
Height 68.0mm300kg (per pair)
5006
Width 24.0-25.4mm
Height 109.0mm110kg (per pair)
5030 - Non Lock
Width 19.5-20.5mm
Height 49.8mm190kg (per pair)
5035 - 100% Extension
Width19.8mm
Height 49.5mm130kg (per pair)
5045 -100% Extension
Width 25.0-26.0mm
Height 68.0mm135kg (per pair)
5045 -140% Extension
Width 26.0-25.0mm
Height 68.0mm92kg (per pair)
